16.5HP Horizontal 4-Stroke Water Cooled Single Cylinder Diesel Engine ZS1105

Name: "16.5HP Horizontal 4-Stroke Water Cooled Single Cylinder Diesel Engine ZS1105"
Rating: 5 (756 reviews)

Quantity:

SKU: 3111581764

Model: ZS1105

Product Details

16.5HP Horizontal 4-Stroke Water Cooled Single Cylinder Diesel Engine ZS1105

Hand Start · Rated Speed 2200rpm · Displacement 0.996L

Product Summary

The ZS1105 is a horizontal, 4-stroke, water-cooled single-cylinder diesel engine delivering 16.5 HP at a rated speed of 2200 rpm. With a bore/stroke of 105x115 mm and displacement of 0.996 L, this engine is built for reliable performance in demanding conditions. It is manufactured by Changzhou Vision International Trading Co., Ltd., a Chinese company with export experience to South America, Africa, Southeast Asia, and the Middle East. The engine is designed for agricultural equipment, engineering equipment, and power generation applications.

Key Selling Points

16.5 HP at 2200 rpm - Sufficient power output for small tractors, water pumps, and generator sets, balancing performance and fuel efficiency.
Optimized fuel consumption of 257 g/kW-h - Low operating cost for continuous-duty applications.
Durable construction - Cast iron cylinder block, steel crankshaft, and aluminum alloy cover ensure long service life and stable operation.
Large fuel tank capacity (12 L) - Extended run time between refuels, reducing downtime in field operations.
Hand-start system - Simple and reliable starting mechanism, ideal for remote or off-grid locations.
Manufacturer direct export - Factory with 32,207.8 m² area, 95 employees, annual output of 100,000 units, and ISO9001/ISO14000 certified quality management.

Technical Specifications

Parameter	Value
Model	ZS1105
Type	Horizontal 4-Stroke Water Cooled Diesel Engine
Starting System	Hand-Start
Rated Power	16.5 HP
Rated Speed	2200 rpm
Bore × Stroke	105 × 115 mm
Displacement	0.996 L
Fuel Consumption	257 g/kW-h
Oil Consumption	2.14 g/kW-h
Fuel Tank Capacity	12 L

Models and Options

This listing covers the ZS1105 model. The company manufactures a broader range of single-cylinder diesel engines from 3 to 45 horsepower, including air- and water-cooled variants. Please contact us for information about other models in the series.

Materials and Structure

Cylinder Block: Cast iron
Crankshaft: Steel
Cover: Aluminum alloy

The horizontal structure provides low profile and easy installation in tractors, pumps, and generator sets. Water-cooled design maintains stable operating temperature for extended use.

Applications

Agricultural equipment
Engineering equipment
Power generation equipment

Typical uses include powering small tractors, water pumps, generator sets, small construction machinery, air compressors, and agricultural product processing machines.

Customization

For customization requests, please contact our sales team. We accommodate packaging, labeling, and documentation requirements based on the destination market.
