Single Cylinder Diesel Engine ZS1132 – 32 HP Hand Start
The ZS1132 is a horizontal four-stroke, water-cooled single-cylinder diesel engine rated at 32 HP. Designed for reliable power delivery in agricultural and industrial applications, this hand-start engine combines a 1.659 L displacement with a sturdy cast-iron construction to ensure long service life and low fuel consumption of 252.7 g/kW-h.
Manufactured in a 32,207.8 m² facility, the Jintian brand engine has passed ISO9001 and ISO14000 certifications. It is widely exported to South America, Africa, Southeast Asia, and the Middle East.
Key Selling Points
Efficient Fuel Consumption
At 252.7 g/kW-h, the ZS1132 minimizes operating costs – ideal for long working hours in irrigation and farming.
Hand Start Simplicity
No electric starter needed, reducing maintenance and battery replacement – perfect for remote fields.
Rugged Cast-Iron Block
Cast iron cylinder block and aluminum alloy cover provide durability in harsh conditions.
Proven Manufacturing
Produced in a factory with ISO9001 and ISO14000 certifications, and an annual output of 100,000 units.
Multi-Industry Use
Powering agricultural equipment, engineering machinery, and generator sets.
Technical Specifications
| Parameter | Value |
|---|
| Model | ZS1132 |
| Starting System | Hand Start |
| Rated Power | 32 HP |
| Rated Speed | 2200 rpm |
| Bore × Stroke | 130 × 125 mm |
| Displacement | 1.659 L |
| Fuel Consumption | 252.7 g/kW-h |
| Oil Consumption | 2.14 g/kW-h |
| Fuel Tank Capacity | 17 L |
Models and Options
ZS1132
Hand Start Version
32 HP / 2200 rpm
As Specified
Materials and Structure
The cylinder block is made of high-strength cast iron, the crankshaft is forged steel, and the cover is cast aluminum alloy. The horizontal water-cooled design provides even temperature distribution and extended engine life.
Applications
🚜
Agricultural Machinery
⚙️
Engineering Equipment
⚡
Power Generation Sets
💧
Water Pumps
Customization
We offer customization options for shaft extensions, paint colors, and packaging. For specific requirements, contact our sales team.
FAQ
What is the MOQ?
The minimum order quantity is one 20 ft container.
What are the accepted delivery terms?
We support FOB and EXW.
What are the payment terms?
We usually accept 30% down payment and 70% before shipment.
How is quality inspected?
You can inspect via video or images.
What is the delivery time?
Specific delivery time is negotiable, depending on order quantity.
Can the engine be used for pumping water?
Yes, it is suitable for water pumps and agricultural equipment.
Does the engine come with a fuel tank?
Yes, the fuel tank capacity is 17 liters.
Get a Quote
Contact us for pricing and availability.
Email: khang@enginezoom.com
Phone/WhatsApp: +86 166-5159-4277
Address: No. 28, Jinsheng East Road, Jintan, Jiangsu, China
Image Suggestions
Use images showing the complete engine from multiple angles (front, top, side) for the main gallery. Detail images can highlight the hand-start mechanism and fuel tank area.
